1042736 120V AC/DC Smoke Alarm with 10-Year Sealed Lithium Battery Backup

SKU: 1042736

Roll over image to zoom

Right click on thumbnail to save image

1042736 120V AC/DC Smoke Alarm with 10-Year Sealed Lithium Battery Backup

Name: 7010LBL - BRK Photoelectric hardwired smoke alarm with 10-Year sealed lithium battery backup. | BRK
SKU: 1042736
Availability: InStock

SKU: 1042736

Hardwired smoke alarm with 10-Year sealed 9V lithium battery backup. AC 120V Interconnectable with Silence and Latching features. Includes Photoelectric smoke sensing tehcnology.

Select a Model:

Find Replacement Products

Find a Rep

Resources


	1042736-7010LBL CSFM Listing Card	10/2019	0.2MB	Download
	1042736-7010LBL ETL Listing Card	08/2019	0.2MB	Download
No Results found for


	1042736-7010LBL User Manual	02/2019	1.3MB	Download
	1042736-7010LBL Specification Sheet	01/2019	0.7MB	Download
	More Information on Ionization vs. Photoelectric Smoke Alarms	01/2023		Download
No Results found for

Specifications
BRK Model	7010LBL
Replacement Model	SM110V-AC
Type	Smoke Alarm
Sensor Type	Photoelectric
Sensor Information	Smoke particles of varying number and size are produced in all fires. For maximum protection, use both ionization and photoelectric sensing technologies. Ionization alarms are generally more sensitive to fast flaming fires and photoelectric alarms are generally more sensitive to smoldering fires.
Sound Level	85dB at 10 feet
Product Height	5.06 in
Product Length	2.35 in
Product Weight	0.65 lb
Product Width	5.06 in
Power Source	Hardwired
Operating Voltage	120V AC 60Hz w/ 9V Lithium Battery Backup
Hardwired Interconnectivity	Yes
Wireless Interconnectivity	No
Battery Backup	Yes
Backup Battery Type	Sealed Lithium
Backup Battery Size	9V
Backup Battery Life	10 Years
Color	White
Ambient Operating Temperature (Min)	40 °F, 4 °C
Ambient Operating Temperature (Max)	100 °F, 38 °C
Operating Relative Humidity (Min)	10% (RH)
Operating Relative Humidity (Max)	95% (RH)
UPC Case	10029054021103
Warranty	10 Years Limited
Features	Battery Backup, Hardwire Interconnectivity
Approvals and Standards	Listed to UL217 Standard

View All

Product Overview

Photoelectric Smoke Sensing Technology
10-Year Battery Backup
Latching Alarm Indicator -Easily identifies initiating alarm even after condition is silenced
Single Test/Silence Button
Perfect Mount- Easy mounting bracket to keep alarm secure over wide rotation for perfect alignment
