SA320 Battery Powered Photo/Ion Smoke Alarm

Discontinued

1 6

SA320 Battery Powered Photo/Ion Smoke Alarm

Name: 1039828 - BRK Dual sensor battery powered smoke alarm with replaceable battery. | BRK
Brand: Brkelectronics

SKU: 1039828

Battery powered Smoke Alarm with replaceable battery with Silence and Latching features. Includes Photoelectric and Ionization smoke sensing technology and 2 AA Alkaline batteries.

Additional Options

Product variants

View Replacement Products

RESOURCES |
SPECIFICATIONS |
OVERVIEW |
REPLACEMENT PRODUCTS |
WORKS WITH |
YOU MAY LIKE
ACCESSORIES |

Resources

Sell (0)

1039828-SA320 CSFM Listing Card 02/2011 0.16 MB Download

1039828-SA320 ETL Listing Card 07/2015 0.03 MB Download

Install (0)

User Manual for SA320 Photo & Ion Smoke Alarm (English, Spanish) 05/2016 1.21 MB Download

1039828-SA320 Specification Sheet 03/2011 0.21 MB Download

1039828-SA320 Architect and Engineering Specifications 01/2011 0.08 MB Download

More Information on Ionization vs. Photoelectric Smoke Alarms 01/2023 - Download

Audio Files (0)

Alarm Sound SA320-1039828 06/2023 0.11 MB Download

Low Battery Sound SA320-1039828 06/2023 0.02 MB Download

Supervisory Chirp SA320-1039828 06/2023 0.02 MB Download

Power Up Indication SA320-1039828 06/2023 0.02 MB Download

Dissipate Capacitor Sound SA320-1039828 06/2023 0.05 MB Download

Training (0)

Specifications

BRK Model

SA320

Type

Smoke Alarm

Sensor Type

Dual Sensor (Photoelectric and Ionization)

Sensor Information

Smoke particles of varying number and size are produced in all fires. For maximum protection, use both ionization and photoelectric sensing technologies. Ionization alarms are generally more sensitive to fast flaming fires and photoelectric alarms are generally more sensitive to smoldering fires.

Sound Level

85dB at 10 feet

Product Height

2 in

Product Length

5 in

Product Width

5 in

Product Weight

0.9 lb

Power Source

Battery Operated

Operating Voltage

Two 1.5V AA alkaline batteries

Wireless Interconnectivity

Battery Type

Alkaline

Battery Size

Battery Replaceable

Yes

Number of Batteries

Color

White

Ambient Operating Temperature (Min)

40 °F; 4 °C

Ambient Operating Temperature (Max)

100 °F; 38 °C

Operating Relative Humidity (Min)

10% (RH)

Operating Relative Humidity (Max)

95% (RH)

Easy Access Battery Compartment

Yes

UPC Case

20029054018957

UPC Number

029054018953

Warranty

10 Years Limited

Features

Easy Access Battery Compartment

Approvals and Standards

Listed to UL217 Standard

Product Overview

Utilise à la fois des capteurs de fumée à ionisation et photoélectriques pour une protection maximale
Deux fonctions de verrouillage : verrouillage de l'alarme et verrouillage en cas de batterie faible
Deux fonctions de mise en sourdine : mise en sourdine de l'alarme et mise en sourdine en cas de pile faible
Alimentation par deux piles AA
Technologie Optipath 360
Conforme aux normes en vigueur dans l’Iowa, le Massachusetts et d’autres régions exigeant des détecteurs de fumée photoélectriques et à ionisation alimentés par piles.
