Alarms / Combo Smoke & Carbon Monoxide Alarms / SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer
Discontinued
1 7

SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer

SKU: SC9120LBL

Hardwired Combo smoke & CO alarm with 10-Year sealed 9V lithium battery backup. AC 120V Interconnectable with Silence and Latching features. Includes Ionization smoke sensing tehcnology and electrochemical carbon monoxide sensor.
View Replacement Products
Brkelectronics

SC9120LBL BRK 120V AC/DC Smoke and CO Alarm - 10YR Lithium Battery - Locked Battery Drawer

SKU: SC9120LBL

Resources

Sell (0)

File Name Date Posted Size

Install (0)

File Name Date Posted Size
SC9120LBL User's Manual Dec 10, 2022 1.2 MB Download
SC9120LBL User's Manual (Spanish) Dec 10, 2022 1.23 MB Download
SC9120LBL Specification Sheet Dec 10, 2022 0.4 MB Download
More Information on Ionization vs. Photoelectric Smoke Alarms Apr 07, 2023 - Download

Audio Files (0)

File Name Date Posted Size

Specifications

BRK Model
SC9120LBL
Replacement Model
SMICO105-AC
Type
Combination Smoke & Carbon Monoxide Alarm
Sensor Type
Ionization
Sensor Information
Smoke particles of varying number and size are produced in all fires. For maximum protection, use both ionization and photoelectric sensing technologies. Ionization alarms are generally more sensitive to fast flaming fires and photoelectric alarms are generally more sensitive to smoldering fires.
Power Source
Hardwired
Current Type
AC; DC
Battery Backup
Yes
Backup Battery Type
Lithium
Hardwired Interconnectivity
Yes
Sound Level
85dB at 10 feet
Product Height
5.69 in
Product Length
2.25 in
Product Width
5.69 in
Product Weight
0.66 lb
Warranty
10 Years Limited
Features
Battery Backup; End-of-Life Warning
Ambient Operating Temperature (Min)
40 °F; 4 °C
Ambient Operating Temperature (Max)
100 °; 38 °C
Ambient Relative Humidity (Min)
10% (RH)
Ambient Relative Humidity (Max)
95% (RH)
Approvals and Standards
Listed to UL 217 Standard; Listed to UL2034 Standard
UPC Case
20029054015376
UPC Number
029054015372

Product Overview

  • 10YR Lithium Battery Backup
  • Locked Battery Drawer
  • Latching alarm indicator - remembers which unit initiated an alarm
  • Single button test/silence
  • Intelligent Sensing Technology™ helps reduce the number of nuisance alarms
  • Perfect Mount - allows for easy alignment of alarm
